Hapa 302

UV flexo system for inline printing up to two colors on blister-lidding foils

Basic Info

  • TECHNOLOGY: Flexo Printing
  • INDUSTRY: Pharma & Healthcare
  • SEGMENT: OTC, Other Pharma & Healthcare

Description

​Hapa’s UV Flexo printing systems are supplied in a number of configurations. The systems can print on a variety of roll fed substrates including Aluminum Foil, Paper, PVC and Tyvek. This solvent free printing technology uses modern UV cured inks that have a pasty consistency, making them ideally suited for use within a pharmaceutical environment. These systems are very compact and can easily be integrated onto continuous or intermittent motion packaging machines.

KEY BENEFITS

  • OptiMate – Hapa’s award-winning HMI, for user-friendly operation
  • Hapa Move – the GMP pharma-compliant machine control architecture
  • Format-free operation
  • Simple and accurate print mat mounting using location pins
  • Easy to handle quick color change inking devices
  • Newly designed ozone-free UV dryer modules provide instant curing of the UV ink
  • Hapa UV Flexo inks are available in any PMS color
  • New design with improved performance and serviceability

KEY OPTIONS
  • Configurations: roll-to-roll (R), on a stand (S), top-mounted (T)
  • Mechanical integration and digital interface to packaging machine (S & T version)
  • Corona pre-treatment
  • Pre-print control unit
  • Random and registered printing
  • 1 – 2 colors
  • Software Backup & Recovery Kit
  • Validation documentation
  • For further options please contact us

RELATED NEWS

Detailed Info

Footprint
Machine depth (mm)1387
Machine height (mm)2020
Machine length (mm)1200
Machine weight (kg)775
Other technical features
Technological applicationBlisters, Deep draw blisters, Trays, Pouches
SubstratesAluminum foil, Paper, PVC, Tyvek
Technical Data
Max advance length (mm)350
Performance
Max number of cycles (cycles/min)100
Technical data
Max printing width (mm)298
Max printing length (mm)350
Max web width (mm)310
Min advance length (mm)50
Min web width (mm)70
Max printing speed (m/min)35
